Complementary
Device location in system Outgoer
Network frequency 50/60 Hz
[Ue] rated operational voltage 400 V AC 50/60 Hz
Residual current tripping technology Voltage independent
[Ui] rated insulation voltage 440 V AC
[Uimp] rated impulse withstand voltage 4 kV
Surge current 250 A
Contact position indicator Yes
Control type Toggle
Mounting mode Clip-on
Mounting support DIN rail
Comb busbar and distribution block compatibility Top: YES
Connection pitch 18 mm between phases
9 mm pitches 8
Height 82 mm
Width 72 mm
Depth 72 mm
Colour Grey (RAL 7035)
Mechanical durability 5000 cycles
Electrical durability AC: 2000 cycles 400 V AC 50/60 Hz
Connections – terminals
- Tunnel type terminal (top or bottom) 1…35 mm2 rigid
- Tunnel type terminal (top or bottom) 1…25 mm2 flexible
Tightening torque 3.5 N.m top or bottom
