Controls:
Type of connector: Type G (BS1363)
Liquid:
Pumped liquid: Water
Liquid temperature range: 0 .. 45 °C
Selected liquid temperature: 20 °C
Density: 998.2 kg/m3
Technical:
Rated flow: 3 m3/h
Maximum flow: 4.6 m3/h
Rated head: 27 m
Primary shaft seal: Carbon/Ceramic
Approvals: CE,VDE,UKCA
Approvals for drinking water: WRAS,ACS
Curve tolerance: ISO9906:2012 3B
Max. pump speed: 5200 rpm
Materials:
Type key, code for materials: A
Pump housing: Composite
NORYL FE1630PW PPE+PS-GS30
Impeller: Composite
NORYL FE1630PW PPE+PS-GS30
Installation:
Range of ambient temperature: 0 .. 55 °C
Maximum operating pressure: 10 bar
Maximum permissible inlet pressure: 6 bar
Pipe connection standard: EN 10226-1
Type of inlet connection: R
Type of outlet connection: R
Size of inlet connection: 1 inch
Size of outlet connection: 1 inch
Pressure rating for connection: PN 10
Electrical data:
Power input P1: 550 W
Rated power – P2: 0.45 kW
Mains frequency: 50 / 60 Hz
Rated voltage: 1 x 200-240 V
Minimum current consumption: 0.01 A
Maximum current consumption: 2.8 A
Enclosure class (IEC 34-5): IPX4D
Insulation class (IEC 85): F
Length of power cable: 1.5 m
Power plug: UK plug
