Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 26 cm
Package 1 Width 17.5 cm
Package 1 Length 32 cm
Package 1 Weight 4.549 kg
Unit Type of Package 2 P06
Number of Units in Package 2 8
Package 2 Height 75 cm
Package 2 Width 60 cm
Package 2 Length 80 cm
Package 2 Weight 44.892 kg
High power contactor, TeSys Giga, 3 pole (3NO), AC-3 <=440V 185A, standard version, 48…130V wide band AC/DC coil
د.إ4,100.00
Main
Range TeSys
Range of product TeSys Giga
Product or component type Contactor
Device short name LC1G
Contactor application Power switching, Motor control
Poles description 3P
[Ue] rated operational voltage <= 1000 V AC 50/60 Hz, <= 460 V DC
[Ie] rated operational current 305 A (at <40 °C) at <= 1000 V AC-1, 185 A (at <60 °C) at <= 440 V AC-3
[Uc] control circuit voltage 48…130 V AC 50/60 Hz, 48…130 V DC
Control circuit voltage limits Operational: 0.8 Uc Min…1.1 Uc Max (at <60 °C), Drop-out: 0.1 Uc Max…0.45 Uc Min (at <60 °C)
