Specifications
Operating Temperature –25 to +55°C (no freezing)
Degree of Protection Terminal: IP20, Housing: IP40
Rated Power Voltage 24V AC (–15 to +10%) 50/60 Hz
24V DC (–15 to +10%)
Power Consumption 5 VA maximum (24V AC)
2.5W maximum (24V DC)
Overcurrent Protection Electronic (Note)
Control Circuit Voltage 24V
Performance Level (PL) e (EN ISO 13849-1)
Safety Category 4 (EN ISO 13849-1)
Safety Integrity Level (SIL) 3 (EN 62061)
HR1S-AF
د.إ455.00
•2NC safety input type, such as E-Stops or Interlock Switches
•EN ISO 13849-1 PLe, Safety Cat 4 compliant, and EN 62061 SIL 3
•Welding detection of start switch
•Fault diagnosis function with dual safety circuits.
•Internal relay operations can be monitored with LED Indicator.
•Finger-safe protection
•22.5mm wide, 35mm DIN rail mounting
•UL listed, CSA certified, TÜV NORD approved
